Geprc Dolphin HD 153mm F4 AIO 20A 2-4S 4 Inch Toothpick RC Drone FPV Racing PNP BNF w/ Caddx Vista HD Digital System - 319.00 €


Geprc Dolphin HD 153mm F4 AIO 20A 2-4S 4 Inch Toothpick RC Drone FPV Racing PNP BNF w/ Caddx Vista HD Digital System
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Specification:
Brand Name: Geprc
Model: Dolphin HD
Item Name: 153mm F4 AIO 20A 2-4S 4 Inch Toothpick FPV Racing Drone
Wheelbase: 153mm
Antenna: RG137 5.8g RHCP
VTX: 5.8GHz (48 Channel IRC Tramp,PIT/25/100/200mW)
Weight: 160g ( without battery)


GEPRC GEP-DX4 153mm Frame Kit

Material: Full 3K carbon fiber

Arm Plate Thickness: 4mm

Other Plate Thickness: 2mm


GEP-20A-F4 AIO Flight Controller Built-in 20A ESC

MCU: STM32F411

Gyroscope: MPU6000

OSD:BetaFlight OSD w/ AT7456E chip

Firmware target: MATEKF411

ESC: 20A * 4 BLHeli_S (Dshot/Multishot/OneShot) support 2~4S LiPo


Geprc GR1507 1507 3200KV Brushless Motor

Input Voltage: 2-4S

Configuration:12N14P

Stator Diamter:15mm


HQProp 4043 3-Blade Propeller

Quantity: 4 CW & 4 CCW


Caddx Vista HD Digital System

Brand Name: Caddx
Item Name: Vista Kit

Operating Frequency: 5.725-5.850GHz
Transmitter Power(EIRP): FCC/SRRC/MIC: <30dBm, CE: <14dBm
Min. Latency (end-to-end): Low Latency Mode(720p 120fps): 21-28ms, High Quality Mode(720p 60fps): 30-40ms
Max. Transmission Distance: FCC/SRRC: 4km, CE: 0.7km
I/O Interface: USB-C,IPEX,3-in-1 Port
Supported Flight Control System: F3,F4,F7
Operating Temperature Range: 32° to 104° F (0℃ ~40℃)
Input Power: 7.4-26.4V
DJI Camera Specifications:
Sensor: 1/3.2'' CMOS
Effective Pixels: 4M
Lens: 2.1mm,f/2.1
Shutter: Rolling shutter
ISO: 100-25600
FOV: 150° (D);122° (H);93° (V)

Features:
- Ultra-light 4 inch toothpick frame, 3K carbon fiber bottom structure, True X frame design, split structure
- High-Quality TPU 3D printed canopy with exquisite design
- 166g weight(without battery), ultra light weight, Enjoying fast and Furious flying
- Equipped with Caddx Vista HD Digital System, the picture quality can reach 720p
- The flight controller uses STM32F411 with MPU6000 gyroscope to work, and BLheli_S 20A ESC, flexibleand smooth flight
- 1507 3200KV motor with HQ4x4.3×3 V1S , Fantastic and efficient power extremely matching
- The PID is meticulouslytestedby the GEPRC Flight team, it can fly as long as press BIND button with your Radio transmitter right on your hand

Pacakge Included:
1x GEPRC Dolphin HD FPV Drone
1x Battery Pad
2x Battery Strap 15x120mm
1x M8 Wrench
1x 1.5mm L Screwdriver
2x Antenna Tubes
