WFLY ET16 2.4GHz 16CH FHSS Transmitter Compatible 4IN1 R9M TBS Crossfire Module with RF209S 9CH Receiver PWM PPM W.BUS Output for RC Drone - 145.00 €


WFLY ET16 2.4GHz 16CH FHSS Transmitter Compatible 4IN1 R9M TBS Crossfire Module with RF209S 9CH Receiver PWM PPM W.BUS Output for RC Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

WFLY ET16 2.4GHz 16CH FHSS Transmitter Compatible 4IN1 R9M TBS Crossfire Module with RF209S 9CH Receiver PWM PPM W.BUS Output for RC Drone


Specifications:

Brand Name: WFLY

Item Name: ET16 Transmitter with RF209S Receiver

Weight: 1500g


RF209S Receiver:

Frequency band: 2.4GHz

Working voltage: 3.5-13V

Working current: 95mA

Resolution: full channel 4096 resolution

PWM: 9CH

PPM: Support

W.BUS: compatible with S.BUS

W.BUS2: Telemetry sensor input

Two-way transmission: support

Out of control protection: support

Online upgrade: support

Relay flight: support

180/270° steering gear: support

Receiver port settings: support

External voltage detection: DC 0-96V

Size: 47*14*25 MM

Weight: 12g


ET16 Transmitter:

Channel: 16 channels

Working voltage: 3.5-13V (1-3S lithium battery)

Working current: 260-400mA

Resolution: full channel 4096 resolution

Frequency band: 2.4GHz (support two-way transmission)

Frequency hopping: new FHSS frequency hopping (64 points, 3.6ms)

Storage: 30 groups of models

Mixing: 10 groups of programming mixing

Language: Chinese‘English

Upgrade: USB online upgrade

Display: 3.5-inch touch screen, 480*320, color screen

180/270° steering gear: support

Voice: Support voice broadcast

Wireless copy: model data

External tuner: support


Featrues:

Support various models of helicopters, fixed wing, multi-rotor, gliders, car, ships, boat, robots and other models

Full channel 4096 resolution (PWM/PPM 4096, S.Bus2048)

3.5-inch Chinese/English color touch screen with 480*320 resolution for outdoor reading

Full channel user-defined switch

Receiver port settings

New frequency hopping protocol, 3.6ms response speed, 64-point frequency hopping, support data return function

Voice broadcast function: telemetering voice, attitude selection, throttle stop, throttle lock, coaching, fine-tuning and other functions broadcast

180/270 degree servo, dual engine function

Support display of each sensor data

Wireless relay flight, wireless copy, wireless transmission of model data

USB online upgrade, 1-3S wide voltage power supply


Package Included:

1 x ET16 Transmitter

1 x RF209S Receiver

1 x Hanging Strap

1 x Voltage Inspection Wire

1 x 18650 Battery Bay

1 x Manual File

1 x Sticks Accessories
