10 PCS Wholesale Realacc RPDB Power Hub Power Distribution Board PDB 5V & 9V & 12V 3-8S BEC - 26.00 €


10 PCS Wholesale Realacc RPDB Power Hub Power Distribution Board PDB 5V & 9V & 12V 3-8S BEC
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

10 PCS Wholesale Realacc RPDB Power Hub Power Distribution Board PDB 5V & 9V & 12V 3-8S BEC

Specification:

Brand name: Realacc
Item name: RPDB Power Hub Power Distribution Board

BEC 5V Output:
-Designed for RC Receivers, Flight controllers, OSD, and Servos.
-DC/DC synchronous buck regulator.
-Voltage: 5.0-5.2V
-Continuous current: 2 Amps

BEC 9V Output:
-Designed for Video TX or FPV camera with linear regulator.
-The battery should be 3S LiPo (10~13V DC)
-Voltage: 9.0-9.2V
-Continuous current: 2 Amps

BEC 12V Output:
-Designed for 12V Device with linear regulator.
-The battery should be 4S LiPo (13~18V DC)
-Voltage: 12.0-12.2V
-Continuous current: 2 Amps

Physical:
-Dimensions: 36.5*46.5mm
-Mounting: 30.5 x 30.5mm, Φ3mm
-Weight: 13.5g

Feature:
-3oz Copper foil, 4 layer, 1.6mm PCB.
-Support the LC filter, reduce wave interference
-Input Voltage: 3-8S
-PDB Output 50A*4, Max. 200A
-BEC Output 5V/2A-9V/2A-12V/2A

Package Included:
10 x RPDB Power Hub Power Distribution Board
