16x16mm GEELANG SIF4 V1 F4 OSD Flight Controller & 13A BLheli_S 2-4S 4in1 Brushless ESC Stack for Anger 75X 85X RC Drone FPV Racing - 37.00 €


16x16mm GEELANG SIF4 V1 F4 OSD Flight Controller & 13A BLheli_S 2-4S 4in1 Brushless ESC Stack for Anger 75X 85X RC Drone FPV Racing
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Specification:

Brand Name: GEELANG

SI-F4FC V1 F4 Flight Controller

MCU: STM32F411CEU6 (100MHZ, 512K FLASH)

Sensor: MPU-6000(SPI connection)

Store: Onboard black box

Board size: 21x21mm

Power supply: 2-4S battery input (DC 7-17V)

Built-in 12A(each) Blheli_S 4in1 ESC Dshot600 ready

Built-in Betaflight OSD(SPI Control)

Built-in Current meter Max 70A

Current meter scale set to 480

Built-in 5V 2A BEC

Built-in voltage detection


13A BLheli_S 4in1 ESC

Onboard 4in1 ESC MCU upgraded to EFM8BB21

Power supply: 2-4S LiPo/LiPo HV (7v/17v)

Current: 13A continuous peak 15A (5 seconds)

Support BLHeliSuite programmable

Default protocol: DSHOT600

Applcation: Compatible with GEELANG Anger 75X / 85X FPV Racing Drone


Package Included:

1x F4 Flight Controller Board

1x 13A ESC Board

1x Buzzer

1x Capacitor

1x Connector

1x bag of Cable
