Beitian BN-180T GPS GLONASS Module for APM Pixhawk CC3D Naze32 F3 F4 Flight Controller RC Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Beitian BN-180T GPS GLONASS Module for APM Pixhawk CC3D Naze32 F3 F4 Flight Controller RC Drone


Specification
Electrical Characteristics Chipset M8030-KT
Frequency GPS L1, GLONASS L1, BEIDOU B1, GALILEO E1, SBAS L1, QZSS L1
Receiving Format GPS, GLONASS, BEIDOU, GALILEO, SBAS, QZSS.
Default GPS, GLONASS, SBAS, QZSS.
Channels 72 Searching Channel
Sensitivity Tracking -167dBm
Reacquisition -160dBm
Cold Start -148dBm
Hot Start -156dBm
Accuracy Position Horizontal 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky)
Velocity 0.1m/sec 95% (SA off)
Timing 1us synchronized to GPS time
Acquisition Time Cold Start 26s
Warm Start 25s
Hot Start 1s
Data Output Support Rate 4800bps to 921600bps, Default 9600bps
Data Level TTL Level
Data Protocol NMEA-0183 or UBX, Default NMEA-0183
NMEA message RMC, VTG, GGA, GSA, GSV, GLL
Concurrent GNSS 1Hz-10Hz, Default 1Hz
Operational Limits Altitude 50,000m Max
Velocity 515m/s Max
Acceleration Less than 4g
Power Consumption VCC DC Voltage 3.0V-5.5V, Typical: 5.0V
Current Capture [email protected]
Mechanical Specifications Dimension 18mm*18mm*8mm
Weight 7.9g
Connector 1.00mm 4pins connector
Environment Operating Temp -40 °C ~ +85°C
Storage Temp -40°C ~ +105°C
LED Built-in LED TX LED: blue. The data output, TX LED flashing
PPS LED: red. PPS LED not bright when GPS not fixed, flashing when fixed

Package Included:
1 x BN-180T GPS GLONASS Module
