BETAFPV Beta85X 4S 85mm Whoop FPV Racing RC Drone PNP/BNF F4 AIO 12A FC V2 1105 5000KV Motors - 149.00 €


BETAFPV Beta85X 4S 85mm Whoop FPV Racing RC Drone PNP/BNF F4 AIO 12A FC V2 1105 5000KV Motors
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Beta85X comes back now with the light F4 AIO 12A FC V2, clear C01 Pro camera, and tough micro canopy! Fast and powerful with the 1105 5000KV motors. Updated F4 AIO 12A FC, which has an 8M Flash chip for Betaflight Black Box and 3 full UARTs (UART1, UART2, and UART6), will definitely give you much more power, enable you to fly on 450mAh 4S battery safely. Perfectly suitable for racing. Fully enjoy the powerful explosive force and an awesome flight experience that the drone brings to you!


Bullet Point

Beta85X pushes the new era of brushless whoop drones to a higher level. With the new power system, you could fly real acro with a C01 Pro camera in racing or freestyle on 4S power.

It comes with upgraded F4 AIO 12A FC, which has an 8M Flash chip for Betaflight Black Box and 3 full UARTs (UART1, UART2, and UART6). Pilots could use one UART for DJI digital FPV unit or Caddx Vista digital FPV unit and the other UART for an external receiver like TBS Crossfire.

Miniature, and lightweight design of C01 Pro camera, weights at only 1.96g, it is with high resolution and 1/3" CMOS sensor, which ensures a high-quality and clear image.

Tough and light enough micro canopy and frame are super suitable for the Beta85X. Whole drone no soldering or tinkering necessary. This canopy adopts with injection molding technique, more durable and flexible.

Powerful 1105 5000KV motor, with lightweight but definitely will give you extreme power and speed to fly on 4S. The motor comes with cable connectors. Just plug and play. EMAX Avan 2" prop is the best combo in this Beta85X drone.

450mAh 4S high rate battery is recommended by default. But pilot could also use their own batteries with battery strap. Optional and affordable.

For 85mm brushless whoop drones, there are 4 versions for your choice - Beta85X FPV, Beta85X HD, Beta85X 4K, and Beta85X for GoPro..


Specification

Item: Beta85X FPV

Weight: 61.88g (without battery)

FC: F4 AIO 12A FC V2

Motors: 1105 5000KV with connector

Props: EMAX Avan 2" 4-Blades Props

FPV Camera: C01 Pro camera

FPV Canopy: Micro canopy

Receiver Option: Frsky XM+ / DSMX / Futaba S-FHSS / Flysky / TBS Crossfire

Battery: 4S 450mAh Battery (Not including)

5.8G FPV antenna

Flight time: 4min - 6min with 450mAh 4S battery (smooth flight in a windless environment)


FC Specifications

CPU: STM32F411CEU6 (100MHZ )

Six-Axis: MPU6000 (SPI connection)

Size: 26mm x 26mm, whoop mounting pattern

Firmware version: BETAFPVF411 (BEFH)

OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)


ESC Specifications

Support BLheli/BLHELI_S suite Pass-through ready

Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600

Input voltage: 2S-4S Lipo

Continue current: 12A

Peak current: 13A

Firmware: BLHELI_S

Processor: SILABS EFM8BB21F16G

Factory firmware: G-H-30-16.7


C01 Pro Camera and VTX

C01 Pro Micro Cam is the lightweight camera customized for those weight-sensitive micro whoop drones. Adapted a 1/3'' CMOS sensor, 2.1mm lens for 1200TVL resolution, and excellent latency while minimizing the weight to 1.96g. At the same time, the 5.8g VTX board has all the other functions of the Z02 camera, like output power switchable between 0mW, 25mW, and 200mW. Smart audio is available for VTX remote control in default.


The C01 Pro camera comes with the FPV version of Beta85X drone. The camera tilt angle is 30 degrees.


Output power: 25mW and 200mW (Adjustable)

Smart Audio function is included for radio control

Frequency: 5.8GHz 6 bands 48 channels, with Raceband: 5362~5945MHz

TV System: NTSC

Lens: 2.1mm(M8) FOV 160°


1105 5000KV Motors

Lower 5000KV for Beta85X 4S, which could support 4S power and won't cause the issue of overheat. Providing stronger thrust in 4S whoop drone. Powerful, fast, and durable.


We DO NOT recommend the 1105 6000KV motors for 4S power because the motor may overheat or burn which will cause permanent damage on the motor or ESC. And don't use 1105 5000KV motors for 3S power, the performance will not be as good as the 1105 6000KV motors since lack of power.


MotorRecommend Battery
Voltage
1105 6000KV
3S 450mAh Battery
11.1V
1105 5000KV
4S 450mAh Battery
14.8V


Props Out

The Beta85X drone also comes with "props out" by default. Why we need "props out" direction?

Default Betaflight props direction, quadcopter dips, and "washes out" in hard corners. With reversed props or "props out", no more dipping even in the hardest cornering.


Package Included:

1 * Beta85X Whoop Quadcopter(4S)

4 * EMAX Avan 2" 4-Blades Props
