DGF1 1/10 RC Car Frame W/ Carbon Fiber Sponge Tire Kit For Racing Drift Car Without Battery Transmitter - 175.00 €


DGF1 1/10 RC Car Frame W/ Carbon Fiber Sponge Tire Kit For Racing Drift Car Without Battery Transmitter
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Description:

Power HD 1206 G2 (1206 Generation 2 second generation) short silent digital servo

Size:410x200mm

Wheelbase:270mm


Recommend to buy:

Servo parameters

Gear: 25T

Weight: 41.0 g

Dimensions: 41.0 X 20.0 X26.4 mm

Performance: 12kg-cm 0.06s @ 7.4V / 9kg-cm 0.07s @ 6V

Working voltage: 6.0 ~ 8.4V

Drive motor: Coreless motor

Gear material: aluminum alloy + titanium alloy (high precision gear made in Taiwan)

Working temperature: -20℃ ~ 60℃

Working frequency: 1520μs / 333hz

540 sensory brushless 3650 motor

Motor parameters (appearance size is the same as Hobbywing V10 series):

Diameter: 36MM

Length: 52.7MM

Output shaft: 3.175MM

KV value: 6.5T 5660KV / 10.5T 3600KV / 13.5T 2800KV

ET120 Easy Turbo 120A 1/10 Sensored Brushless ESC

model

Easy Turbo ET120

Continuous current / peak current: 120A / 760A

Support motor type: brushless motor and brushless motor

Main applicable models: 1/10 RV, off-road vehicle, drift car, F1, etc.


Support brushless motor T number (remarks)

4-6 Ni-MH or 2 Lithium batteries ≥3.5T (1/10 RV), ≥5.5T (1/10 off-road)

8-9 NiMH or 3 Lithium batteries ≥8.5T (1/10 RV), ≥10.5T (1/10 off-road)

Number of batteries: 4-9 Ni-MH batteries, 2-3 Lithium batteries

BEC output voltage: 6V@3A, switching regulator mode

Fan working voltage: get the working voltage directly from the battery (if you use 3S battery, you need to plug the fan plug into the receiver to get power)

Bottom size / weight

43* 36* 33mm (including the height of the fan) / 105 grams (including the weight of the wire fan)


Note:

The car shell is transparent.

This only a car frame,not included any electric parts.


Package included:

1x frame
