DJI Livox Mid-100 Lidar Sensor 30W 260m @80% Reflectivity 2cm 0.1°Distance Angle Accuracy for RC Drone UAV Robotics - 1 699.00 €


DJI Livox Mid-100 Lidar Sensor 30W 260m @80% Reflectivity 2cm 0.1°Distance Angle Accuracy for RC Drone UAV Robotics
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

DJI Livox Mid-100 Lidar Sensor 30W 260m @80% Reflectivity 2cm 0.1°Distance Angle Accuracy for RC UAV Robotics

Specs:
Brand Name: DJI
Item Name: Lidar
Model: Mid-100
Laser Wavelength: 905 nm
Laser Safety: Class 1 (IEC60825-1)
Detection Range (@100klx): 90m @ 10% reflectivity
130 @ 20% reflectivity
260 @ 80% reflectivity
FOV: 98.4°(Horizontal) x 38.4°(Vertical)
Range Precision: 2cm
Angular Accuracy: < 0.1°
Beam Divergence: 0.28°(Vertical) x 0.03°(Horizontal)
Point Rate: 300,000 points/s
FOV Coverage: 20% @0.1s, 68% @0.5s, 93% @1s
False Alarm Rate(@100 klx): <0.01%
Operating Temperature: -4°F to 149°F(-20°C to 65°C)
IP Rating: IP67
Power: 30W typical
Data Interface: Data Interface
Time Synchronization: IEEE 1588-2008(PTP V2),
PPS(Pulse Per Second)
Dimensions: 142x70x230mm
Weight: Approx. 2200g

Features:
- 260 m @ 80% Reflectivity
- 2 cm Range Precision
- 0.1° Angular Accuracy
- Non-Repetitive Scan Pattern
- High Reliability

Package Included:
1 x Mid-100
1 x Livox Convertor
12 x M3x10 Screw
1 x Livox Power Cable
1 x Livox Sync Cable
1 x Mid-100 Quick Start Guide
1 x Front Window Cleaning Cloth
