Specification:
Brand: DJI
Item Name: RSC 2
Peripheral Equipment:
| Accessory Interface | 1/4" Mounting Hole, 3/8" Mounting Hole, Camera Control/Accessory Interface, Charging Interface USB-C, RSA Accessory Expansion Interface |
Battery | Model: RB2 3400mAh 7.2V Model: RB2 3400mAh 7.2V Type: 18650 2S Capacity: 3400mAh Energy: 24.48Wh Maximum Standby Time: 14 Hours Charging Time: 18W fast charge for about 2 hours to fully charge (support QC 2.0 and PD protocol) Suggested Charging Environment: 5â~40â |
Support Interface Type | Bluetooth 5.0, Interface USB-C |
Ronin APP Installation Requirements | IOS 9.0 aboveï¼Android 5.0 above |
Work Characteristics:
Load Weight | â¤2.0kg |
| Angle Jitter | ±0.02° |
| Controllable Rotation Range | Translation Direction: 360° Continuous Rotation Pitch Direction: -90°~145° Rolling Direction: ±30° |
Maximum Controllable Speed | Translation Direction: 180°/s Pitch Direction: 180°/s Roll Direction: 180°/s |
Mechanical Limit Range | Yaw Axis Unlimited Roll Axis -95°~+220° Pitch Axis -202.5°~+112.5° |
Mechanical and Electronic Properties:
Working Frequency | 2.400GHz~2.4835GHz |
Transmit Power | â¤8dBm |
| Working Current | Quiescent Current: 0.2A |
Working Temperature | -20â~45â |
Size | Gimbal Folding Status: 220*200*75mm Working Status: 370*165*150mm |
| Weight | Gimbal: 830g Handle: 258g Tripod: 160g |
Compatibility Search :
https://www.dji.com/support/compatibility?product=rsc-2&from=nav
Downloads:
https://www.dji.com/rsc-2/downloads
Features:
1. It is made of lightweight alloy, supplemented by high-strength materials, and weighs only 1.1 kg. It's comfortable to hold and can easily shoot stable and smooth videos.
2. The torque is strong, and the maximum load reaches 2 kg. The shutter cable supports mainstream camera brands, and can control the shutter and follow focus. It has good compatibility and can be used by most major mirrorless cameras.
3. More stable and quick response. In the sport mode, the user's action changes will be detected in real time, and the following speed of each axis will be dynamically adjusted to be able to follow quickly. Take a variety of fast-moving shots.
4. Innovative structure design, unique shooting experience. Innovative non-orthogonal gimbal design, not easy to block the camera screen, can better adjust the composition when shooting; in the direction lock mode, with the unique gimbal structure can achieve seamless switching between high and low camera positions.
5. The 360° infinite position of the translation axis can realize continuous rotation and bring a dazzling effect.
Package Included: ï¼Optionalï¼
List | SC | Ronin-SC |
Gimbal Main Body | 1 | 1 |
BG18 Handle (Built-in Battery) | 1 | 1 |
Handle Extension Tripod (Plastic Version) | 1 | 1 |
| Camera Quick Release Board | 1 | 1 |
| Camera Boost Template | 1 | 1 |
| Suitcase | 1 | 1 |
| Phone Holder | 1 | 1 |
| Lens Fixing Bracket | 1 | 1 |
| Interface Protection Cover | 2 | 2 |
| Wrench | 2 | 2 |
| Camera Fixing Screw 1/4"-20 | 3 | 3 |
| Screw M4 | 4 | 4 |
| Multi-function Camera Control Line (Multi) | 1 | 1 |
| Multi-function Camera Control Cable (Type-C) | 1 | 1 |
| USB-C Line | 1 | 1 |
| Multi-function Camera Control Cable Adapter (Type-C to Micro-USB) | 1 | 1 |
Focus Motor | / | 1 |
Follow Focus Motor Mounting Components | / | 1 |
| Follow the Focal Wheel | / | 1 |
| Follow Focus Device and Focus Rack | / | 1 |
Screw | / | 6 |
| SC RSS One Point Two Lines | / | 1 |
