Eachine Vwhoop90 Brushless Tiny Whoop Tiny Whoov 2-in-1 FPV Racing Drone with Crazybee F3 700TVL Cam - 89.00 €


Eachine Vwhoop90 Brushless Tiny Whoop Tiny Whoov 2-in-1 FPV Racing Drone with Crazybee F3 700TVL Cam
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Eachine Vwhoop90 Brushless Tiny Whoop Tiny Whoov 2-in-1 FPV Racing Drone with Crazybee F3 700TVL Camera BNF

Description:

The world first Amphibian Drone is coming, it’s not only a tiny hovercraft , you can transformer it to a Tiny whoop and rush to the sky during Driving anytime. That’s more funny and awesome.

Specifications:
Brand: Eachine
Model: Vwhoop90
Item Name: 1S Brushless Vwhoop 2-in-1 FPV Racing Drone
Size:155mm*120mm*30mm
Weight:36g (without battery)
Fly Weight: 42.5g (with Original 3.8v 250mah Lipo battery)

SE0802 KV19000 Motor Mode SE0802 KV19000
Configuration 9N12P
Stator Diamter 8.4mm
Stator Length 2mm
Shaft Diameter Φ1.0mm
Motor Dimension(Dia.*Len) Φ10.5mm*14.9mm
Weight(g) 1.7g(without connector and cable)
No.of Cells(Lipo) 1S
Servo Weight 3.7g (Without connector and cable)
Dimension 20.0x17.6x8.0mm
Supply Voltage 4.8~6.0V
Stall Torque 0.4kg.cm
Operating Speed 0.12sec/60° (NO Load Running)
Flight Controller Firmware Betaflight_3.3.0_Crazybee
Betaflight Target CRAZYBEEF3FR (Frsky version)
CRAZYBEEF3FS (Flysky version)
MCU STM32F303CCT6 (72MHZ, 256K FLASH)
Sensor MPU-6000 (SPI Connection)
Board Size 28.5 * 28.5MM
Board Weight 3.5g
Power Supply 1S Battery Input (DC 3.5-4.35V)
- Built-in 5A (each) Blheli_S 4in1 ESC Dshot600 ready
- Built-in Frsky receiver with telemetry (D8/D16 switchable)
- Built-in Betaflight OSD (SPI Control)
- Built-in Current meter Max 14A
- Built-in 5V 0.8A BEC with LC filter
- Built-in voltage detection
- BLHELI_S pass-through Ready
- Heading LED Ready
Onboard 4-in-1 5A ESC Power Supply 1S LiPo/LiPo HV (4.2v/4.35v)
Current 5A continuous peak 6A (3 seconds)
Factory Firmware O_L_5_REV16_6.HEX
Default Protocol DSHOT600
Support BLHeliSuite programmable
Frsky Receiver Version Channels 8ch or 16ch
No ground interference ( Transmitter and receiver 1m from the ground) 300m
- SPI BUS receiver
- Frsky D8/D16 switchable
- Compatible both D8 and D16 transmitter
- Failsafe support
Flysky Receiver Version Protocol AFHDS and AFHDS-2A Switchable
Channels 8ch(AFHDS) or 14ch(AFHDS-2A)
No ground interference ( Transmitter and receiver 1 m from the ground) 300m
- SPI BUS receiver
- Failsafe support
AIO Camera & VTX Output Power 25mw
Frequency 48CH
Input Voltage 3.3V 5.5V
Current Consumption 300mA (type)
Camera Resolution 700TVL
Field of View 120°
Video Format NTSC
Antenna RG178 Antenna
Frequency 5.8GHz 6 bands 48 channels
With Race Band 5474 5945 MHZ
Size 13.9"12.0mm ( L*W )
Weight 3g
Lipo Battery Capacity 250mAh
Voltage 3.8V
Continuous Discharge Rate 30C
Instantaneous Discharge Rate 60C
Size 60mmx18mmx7mm
Weight 6.5g
Connector PH2.0

Package Included:
1 x Vwhoop90 Frame
1 x Crazybee F3 Flight controller (Option Frsky or Flysky or DSM)
4 x SE0802 KV19000 Brushless Motor
1 x 5.8G 25mw 40ch VTX&Camera
1 x Servo
4 x Propeller
3 x 3.8v 250mah 30C/60C Lipo Battery
1 x USB Charger
