iFlight SucceX-E F4 Flight Controller OSD & 45A Blheli_S 2-6S 4 In 1 Brushless ESC Stack 30.5x30.5mm for RC Drone Frame - 53.00 €


iFlight SucceX-E F4 Flight Controller OSD & 45A Blheli_S 2-6S 4 In 1 Brushless ESC Stack 30.5x30.5mm for RC Drone Frame
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

SucceX-E F4 Flight controller Specification:

MCU: STM32F405
IMU: MPU6000
OSD: AT7456E
Blackbox: 8MB
4X Uarts(1 2 3 6)
8X Dshot/Proshot/Oneshot output
8X individual ESC power/ signal pads
1X Group of Gnd/Vbat/M1/M2/M3/M4/Cur/TX
Smart audio & Tramp VTX protocol: YES(IRC Tramp)
WS2812 led Strip: YES
Baro: No
Beeper: YES
PDB Specifications
Input: 2-8S(50V)
BEC: 5V/3A cont
FC Firmware
Betaflight
Target: STM32F405
FC: IFRC/IFF4_TWIN_G(STM32F405)
Physical
Mounting: 30.5*30.5mm, φ4mm with Grommets φ3mm
Dimensions: 36*36mm
Weight: 7.6g

SucceX-E 45A 4in1 ESC Specification:
- Dimension: 40*43mm
- Mounting Holes: 30.5*30.5mm/Φ3mm
- Weight:14.4g
- Supports 2-6S Lipo input
- STM32F051 MCU, 48Mhz Runs BLHELI 32.X Firmware
- Current sensor: No
- BEC: No
- Supports: DShot DShot150/300/600/MultiShot/ OneShot etc.
- Target: G-H-30 BLS 16.7

Package Included:
1 x SucceX-E F4 Flight Controller
1 x 45A 4 in 1 Brushless ESC
