Jumper X86 86mm 5.8G 32CH F3 7DOF FPV Racing Drone BNF w/ OSD BEC 600TVL Camera Frsky D8 Receiver - 139.99 €


Jumper X86 86mm 5.8G 32CH F3 7DOF FPV Racing Drone BNF w/ OSD BEC 600TVL Camera Frsky D8 Receiver
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Jumper X86 86mm 5.8G F3 7DOF FPV Racing Drone BNF w/ OSD BEC 25mW 32CH VTX Frsky D8 Receiver

Note: This version without battery and charger.








Specification:
Brand name: Jumper
Item name: X86 5.8G F3 7DOF FPV Racing Drone
Wheelbase: 86mm
Frame Size: 118x118mm
Flight controller: F3 7DOF(MPU6000+STM32F303) & OSD & Race timer &BEC
Motor: 1104 7500KV
ESC:2S 10A(D-SHOT)
AV Wireless Transmitter: 5.8g 25mw
Batterry: 2S 500mah 25c Lipo battery (Not included)
Flight time: 5-6 minutes
Drone wight: 78g
Takeoff weight: 105g
Package weight: 164g
Package Size: 150x140x66mm


Camera:
SENSOR: 1/4"" HD Sensor
Resolution: 1280*960
Pixel: 5MP
Definition: 600TVL
Min.Illumination: 0.5Lux
SNR: >48db
GAMMA: 0.45
Refresh rate: 60F/S NTSC,50F/S PAL
Shutter Speed: PAL;1/50'1/100,000s NTSC:1/60'1/100,000s
Working temperature: -40~+85℃
White balance: automatic
Video output: 1vp-p75 Europe
Synchronous system: Internal synchronization
TV Format: PAL

Frequency Table S4=ON,S5=ON S4=OFF,S5=OFF S4=ON,S5=OFF S4=OFF,S5=ON S3 S2 S1 5.740 5.865 5.733 5.705 OFF OFF OFF 5.760 5.845 5.752 5.685 OFF OFF ON 5.780 5.825 5.771 5.665 OFF ON OFF 5.800 5.805 5.790 5.645 OFF ON ON 5.820 5.785 5.809 5.885 ON OFF OFF 5.840 5.765 5.828 5.905 ON OFF ON 5.860 5.745 5.847 5.925 ON ON OFF 5.880 5.725 5.866 5.945 ON ON ON


Package included:
1 x X86 Frame kit
4 x 1104 motor
4 x 10A ESC
2 x CW Propeller
2 x CCW Propeller
1 x F3 7DOF &OSD Flight controller
1 x 600TVL Camer
1 x Frsky D8 Receiver
