LDARC ET75 FPV 74mm F4 OSD 3S FPV Racing Drone PNP BNF w/ 200mW VTX Runcam Nano 2 Camera - 112.00 €


LDARC ET75 FPV 74mm F4 OSD 3S FPV Racing Drone PNP BNF w/ 200mW VTX Runcam Nano 2 Camera
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

LDARC ET75 FPV 74mm F4 OSD 3S FPV Racing Drone PNP BNF w/ 200mW VTX Runcam Nano 2 Camera

Specification:
Brand Name: LDARC
Model: ET75 FPV
Item Name: 74mm F4 OSD FPV Racing Drone w/ Runcam Nano 2 Camera
Version: PNP ( Without Receiver) ; BNF ( With AC2000 Receiver)
Drone Wheelbase:74mm
Weight: 41.7g ( without battery)
F4 OSD Flight Controller Brand Name: LDARC
Firmware: MATEKF411
MCU: STM32F4AA
MPU: MPU6000
BEC: 5V 1.5A
Onboard Current Sensor
Onboard ESC
Support SBUS DSM2/X iBUS Receiver
Onboard 12A BLheli_S ( G_H_30) 4in1 ESC Con. Current: 12A
Max. Current: 20A
Support 2-4S Lipo
Firmware: BLheli_S
Onboard AC2000 Receiver ( Only BNF Version has) Item Name: AC2000 Receiver
Rated voltage: 4.0V~6.0V
Support S-FHSS(8 CHs)/D16 non-EU(14 CHs)/D16 EU-LBT(14 CHs) three modes, output S.BUS signal
Perfect fit high reliability medium and small size drone
The channel 16 of S.BUS value is real-time RSSI, BETAFLIGHT OSD can display this RSSI value in screen.
48CH 0/25/100/200mW VTX Brand Name: LDARC
Channel: 40CH
Power: 0/25/100/200mW Switchable
Input Votlage: 2-4S
Support IRC Tramp
51mm 3-Blade Propeller Brand Name: LDARC
Item Name: 51mm 3-Blade Propeller
Color: Black
Quantity: 10 CW & 10 CCW
XT1102 9300KV Motor Brand Name: LDARC
Model: XT1102
Item Name: 1103 9300KV
Shaft Diameter: 1.5mm
Input Voltage: 2-3S

Motor Mounting Hole Size: 6.6 ( M1.4)
Weight: 2.8g
Runcam Nano 2 700TVL Camera
Brand name: Runcam
Model: Nano 2
Image Sensor: 1/3" CMOS
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 155°
Signal System: NTSC / PAL
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Auto Gain Control (AGC): Auto
Min. Illumination: [email protected]
D-WDR: Auto
Day/Night: Color
Power: DC 3-5.5V
Housing Material: ABS
Net Weight: 3.2g
Dimensions: L14mm*W14mm*H16mm
Lipo Battery ( All Version Have) 3S 11.4V 300mAh 30C Lipo Battery

Pacakge Included:
1x LDARC ET75- FPV Drone
1x Displaying Rack
1x Battery
4x ET75 Pillar
1x Tool
