Lumenier AXII HD Antenna Combo 5.8GHz 8.2dBi 2.2dBi LHCP RPSMA Set for DJI Digital HD FPV Goggles - 72.00 €


Lumenier AXII HD Antenna Combo 5.8GHz 8.2dBi 2.2dBi LHCP RPSMA Set for DJI Digital HD FPV Goggles
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Lumenier AXII HD Antenna Combo 5.8GHz 8.2dBi 2.2dBi LHCP RPSMA Set for DJI Digital HD FPV Goggles


Features
Circularly Polarized
Designed for DJI HD Digital FPV Goggles, form fitting
Compact low-profile design on your goggles, easy to store and transport
High 8.2 dBiC for long range and improved signal penetration
Wide 68 degree beam width on patch antennas, 360 degree on stubby
High antenna efficiency for improved signal
It is capable of receiving signal up to many miles away


Specifications
AXII HD Patch Antenna
Frequency: 5.8GHz
Bandwidth: 220 Mhz
Gain: 8.2 dBiC
VSWR: 1:1.1 - 1:1.3
Radiation Efficiency: 92%
Beam Width: 68° H. 68° V.
Polarization: (LHCP) Left Hand Circularly Polarized
Connector: RP-SMA (Fits DJI Goggles directly, not to be used on standard SMA)
Dimensions: 73mm x 35mm x 9mm (21mm with SMA)
Weight: 22g each

AXII HD Stubby Antenna
Gain: 2.2dbic
Axial ratio: 1.0 (near perfect)
Bandwidth: 5.3GHz-6.2GHz
Radiation Efficiency: 98%
Beam Width: 360 degrees (omni-directional)
SWR: <=1.5:1
Weight: 6g
Size: 26mm x 17.5mm
Connector: RP-SMA (custom long)
Works great as both a transmitting or receiving antenna
Compatible with other styles of 5.8GHz RHCP antennas
Polarization: (LHCP) Left Hand Circularly Polarized


Package Included
2x Lumenier AXII HD Patch Antennas (LHCP)
2x Lumenier AXII HD Stubby Antennas (LHCP)

Note: These are sold as single units. We suggest buying 2 or 4 to make a set for your goggles.
