Specification:
MAMBA F722S Flight Controller:
MCU: STM32 F722
SIX-AXIS: MPU6000
FLASH: 16M
OSD: YES
BEC: 5V 2A & 9V 2A
Controller: 4 Set 2812 LED
Bluetooth: SpeedyBee APP
UART: 6 Set
Input: 3~6S Lipo (12.6V~25V)
Mounting: 30.5mm/M3
Product size: 37.9×37.9mm
Weight: 6g
MAMBA 506 50A 3-6S Dshot1200 4IN1 ESC:
INPUT VOLTAGE: 3~6S Lipo (12.6V~25V)
CONTINUE CURRENT: 50A×4
BURST CURRENT: 55A (10S)
BEC: NO
SOFT: Dshot300/600/1200
MOUNTING: 30.5mm/M3
Supply: Pana sonic High Frequency 470uF/35V
Product size: 36.5×46.5×6.4mm
Weight: 11.5g (ESC) 3.1g (Cooling fin)
Package Included:
1 x MAMBA F722S Flight Controller
1 x MAMBA 506 50A 3-6S Dshot1200 4IN1 ESC
