SPCMaker Bat78HD-S 78mm F4 AIO 20A ESC 2S Whoop FPV Racing Drone RTF w/ 25/400mW VTX RunCam Split 3 Nano Camera Radiolink T8S Radio Transmitter - 254.00 €


SPCMaker Bat78HD-S 78mm F4 AIO 20A ESC 2S Whoop FPV Racing Drone RTF w/ 25/400mW VTX RunCam Split 3 Nano Camera Radiolink T8S Radio Transmitter
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Specification:

Brand Name: SPCMaker

Model: Bat78HD-S

Item Name: 78mm F4 AIO 20A ESC 2S Whoop FPV Racing Drone

Version: RTF

Product Size: 107x95x35mm

Weight: 59g (without battery)

Packing: portable storage handbag

Packing size: 215x220x125mm


F4 OSD Flight Controller AIO 20A ESC Board

CPU: STM32F411CEU6 (100MHZ)

IMU: MPU6000 (SPI)

OSD: AT7456E

LED: Support WS2812 and other programmable

Sensor: Built-in current sensor (current coefficient Amp Meter Scale: 300)

Firmware: Betaflight 4.1.2

Flight control model: MTKS/MATEKF411 (STM32F411)

Receiver support: Frsky/Futaba/Flysky/TBS Crossfire/DSMX|DSM2 receiver

Size: 31.4x31.4mm (25.5mm mounting hole)

Weight: 6.83g

Onboard 20A BLHeli_S 4in1 ESC

Firmware support: BLHELI_S/JESC

Protocol support: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600

Input voltage: 2S-4S Lipo

Continuous current: 20A

Peak current: 40A

Firmware version: BLHELI_S (Q_H_20)

Motor connector: 1.25mm 3P straight pin socket

1103 11000KV Brushless Motor

Model: 1103 11000KV

Height: 8.5mm

Shaft: φ1.5mm

Motor mounting hole: hole pitch 9mm screw hole M2

KV: 11000KV

Input Voltage: 2-3S lithium battery

Cable length: 40mm

Weight: 3.3g

Gemfan 1636 40mm 4-Blade Propeller

Brand: Gemfan

Name: 1636 40mm 1.5mm propeller

Number of blades: 4 blades

Pitch: 3.5 inches

Material: PC

Weight: 0.61g

Inner diameter of center hole: 1.5mm

Paddle diameter: 40.8mm

Center thickness: 5.2mm

Maximum width: 7.46 mm

5.8G 40CH 25-400mW VTX

Brand: SPCMAKER

Model: NANO VTX V1.0

Video format: NTSC / PAL

Power: 25/100/200/400mW

Control mode: Betaflight OSD control (RX)/button

Input voltage: 5V

Size: 14 x15mm

Pitch: 18 mm

Antenna: IPEX

Weight: 2g

RunCam Split 3 Nano FPV Camera

Brand Name: Runcam

Item Name: Split 3 Nano whoop

Field of View(FOV) : Recording FOV: 165°; FPV FOV: 165°@16:9, 130°@4:3

Video Resolution: 1080@60fps / 1080@50fps / 1080@30fps / 720@60fps

TV Mode: NTSC (720*480) / PAL (720*576) Switchable

Interface: JST 1.25mm / UART

Max Micro SD Card Supported: 64G(need Class 6 or above, recommend Class 10 / UHS-I / UHS-II / UHS-III)

Hole Distance of Installation: 25.5*25.5mm

Dimensions: PCB 29*29mm / Lens Module 14*14mm

Power Input: DC 5-20V(Non-direct power supply from battery. Powered direcly with battery will generate surges and burn the camera.)

Working Current: 650mA @5V / 270mA @12V

Weight: 10.5g

Radio Tranmitter & Receiver

Brand Name: RadioLink

Product name: T8S transmitter with R8SM receiver

Weight: 142g

Colour: Black

Size: 162.5x 95.5x57 mm (transmitter)

Working voltage: 4.2V

Working current: <150 (±5) mA

Support R8EF, R8FM, R7FG, R7F, R6FG, R6F receiver

Product name: R8SM receiver

Model: R8SM

Size: 18 * 13 MM

Weight: 2g

Number of channels: 8 channels

Signal output: SBUS / PPM

Working voltage: 4.8-6V

Working current: 30mA (input voltage: 5V)

Compatible T8S / T8FB / RC6GS / RC4GS receiver

2S 7.6V 450mAh 80C Lipo Battery

Model: High Energy 7.6V 450Mah 80C

Capacity: 450mAh

Quantity: 2 PCS

Size: 14x18x 62mm

Plug: XT30 plug

Continuous discharge rate: 80C

Weight: about 28g

Hawkeye Display Screen

Model: Hawkeye 3.5-inch xitu version

Display resolution: 960x240

Backlight: LED

Size: 3.5 inches

Brightness: 350Lux

Aspect ratio: 16:9

Response time: <10ms

Color system: PAL / NTSC

Battery life: about 2.5 hours

Signal: Video (PAL/NTSC/Auto)

Display size: 66×57×14mm

Gross weight: 110g

5.8G sensitivity: -94dB

SKYRC E3AC Charger

Model: SKYRC E3AC charger

AC input: 100-240VC, 50-60Hz

Battery type: LiPo

Number of batteries: 2-3S

Charging current: 1.2A maximum

Battery termination voltage: 4.2V±0.02V

Circuit power: 11W±10%

Size: 88x57x35mm

Weight: 103g


Pacakge Included:

1x Bat78 HD Whoop Drone

8x GEMFAN 1636 40MM 4CW+4CCW propeller

1x T8S+R8SM remote control

1x Hawkeye 3.5-inch xitu version

1x E3AC (2-3S) charger

2x 2S 450mAh 80C lithium battery

1x USB tuning parameter connection data cable

1x Storage handbag
