Specifications
FC
MCU: STMF722RET6
Gyro: MPU6000
Memory: 16M
Input Voltage: 12v-25-2v (3-6S)
BEC: 5V/2A
Dimensions: 37mm x 37mm
Mounting Holes: 30.5mm x 30.5mm
Weight: 7.4g
Firmware Target: TMOTORF7 (Betaflight)
ESC
Continuous current: 4*55A
BLHeli_32 32bit
Burst current: 4*75A
BEC Output: 10V @2.0A
Size: 45x41x7.3mm
Weight: 17.3g (Including Heatsink)
Support DSHOT150/300/600/1200
Package Included:
1* T-Motor F55A PRO II + F4 HD STACK
4* M3×30 Screw
4* M3 Non-Slip Nut
4* M3×3 White Hollow Isolation Column
12* M3×3 White Hollow Isolation Column
1* Insulation Sheet
1* Electrolytic Capacitor
1* Power Cord
4* Link Board
2* Graph Connection Line
2* ESC Cable
1* Round and Strips F Stickers, T-Motor Sticker
