VTX-5808 PRO-A HV 40CH 25mW/200mW/500mW/800mW Adjustable Analog Video FPV Transmitter for RC Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

VTX-5808 PRO-A HV 40CH 25mW/200mW/500mW/800mW Adjustable Analog Video FPV Transmitter

Description:

MX VTX-58XX PRO HV serial analog video transmitters are newly designed for FPV flight, it can satisfy our customers for its optimized multifunction: Support MX-SmartVTX protocol, support manually timely controlled power (No need to enter set up menu of VTX to change VTX power during flight), user-friendly installation way etc.
This is VTX-5808 PRO-A HV version.

Specifications:
Item Name: VTX-5808 PRO-A HV
Input Voltage: 7.4~26.0V (2~6S)
Output Power: 13DBm (25mW), 23DBm(200 mW), 27DBm(500 mW), 29DBm(800 mW)
Power Output: 5V/2A
Working Channels: Band A, B, E, Fatshark 8ch, Race Band 8ch
Shielding Cover: Yes
Antenna Port: SMA
Size: 36.0x36.0x4.8mm
Hole Distance for Installation: 35.0x35.0mm & 30.0x30.0mm
Hole Diameter: Φ3.0mm
Weight(not including antenna): 6.5g
MX-SmartVTX or SmartAudio Protocol: Support
Timely Manually Power Control: Support
Audio Input: Not support

Features:
- MX-SmartVTX protocol (Note 1)
- Support PWM signal power control (for timely setting up VTX power manually)
- LED light indicates VTX power timely
- Global commonly used 40CH frequencies
- 25MW output (Maximum 800MW, Note 2)
- Its power will be 25MW when it enters power set up mode
- Hole installation position for version A: 30.5*30.5mm (also can be installed on 30.0*30.0mm)
- Hole installation position for version B:20.0*20.0mm
Note 1: MX-SmartVTX is a protocol connecting VTX and Flight control board, which is for setting up working frequency and power on VTX in graphical way.
Note 2: The maximum power output will be different for different version.

English Manual, Click Here

Package Included:

1x VTX-5808 PRO-A HV Video FPV Transmitter
