MATEKSYS Matek System VRX-1G3-V2 1.2/1.3GHz 9CH Wid Band FPV Receiver Video Receiver RC FPV Drone Long Range - 45.00 €


MATEKSYS Matek System VRX-1G3-V2 1.2/1.3GHz 9CH Wid Band FPV Receiver Video Receiver RC FPV Drone Long Range
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Video

Features & Specifications

  • Receiving frequency: 9CH (1080MHz to 1360MHz)
  • RX Sensitivity: -95dBm
  • Band-pass filter 950MHz~1450MHz
  • Dual input options: 4~5V via pins or 6-30V via “DC” pad on VRX-DK
  • Button control and LED indicators
  • VRX-DK input voltage 6~30V (“DC” pad)
  • VRX-DK regulator output: 5V 2.5A
  • Current Consumption: 0.3A @5V
  • Video format: NTSC or PAL
  • Video Output impedance: 75Ω, Typ.
  • Audio Subcarrier Frequency: 6.5 MHz & 6.0MHz
  • ANT. input impedance: 50Ω, Typ.
  • RF Connector: SMA
  • 2.54mm pins and PCB size are compatible with FS module
  • 5pins (5V, Gnd, A6.5, A6.0, Video) work with FS dock
  • Weight: 12g ( w/o dock), 19g (w/ dock)
  • Size: board 43*27mm

Includes

  • 1x 1.2/1.3G Video receiver VRX-1G3-V2
  • 1x VRX-DK
  • 1x Dipole antenna_SMA, center freq 1240MHz

Settings

  • Press and hold the button 2 seconds to enter the frequency setting. Frequency LED blinks
  • Press the button to select the frequency
  • When the LED blinks at new frequency, RF input is enabled on this frequency.
  • New frequency will be saved if no button action within 3 seconds
